0.5~2Liter,5Liter,10Liter,20Liter,50Liter Digital Rotary Evaporator

Place of Origin : China

Brand Name : Greatwall

Certification : ISO 9001:2008

Model Number : R-1001VN/LN,R1005,R1010,R1020,R1050

Price : US $1,077 - 6,159 / Unit

Packaging Details : wooden box

Delivery Time : within 10 working days after receiving the payment

Payment Terms : T/T

Supply Ability : 200 sets/month

MOQ : 1 sets

Contact Now

Zhengzhou Greatwall Rotary Evaporator

Brief introduction of Rotary Evaporator:

- Ideal for Distill of (Mixed) Solvent, Condensation Solution and Suspension, Concentrate Liquid, Re-crystallizaton, Dry Powder and Granulate, Synthesize Chemical, Soxhlet Extraction, Recycle Solve.

- Water Bath Electric Lift, Easy to Use.

- Teflon(PTFE) and Fluorine Rubber Dual Rotating Seal, Patented Technology to Ensure High Vacuum.

- A Vacuum Switching Valve, without Affecting the System Vacuum Distillation of the Situation and the Solution can be Continuously Collected.

0.5~2Liter,5Liter,10Liter,20Liter,50Liter Digital Rotary Evaporator

Complete sets of 50L Rotary Evaporator:

Chiller (DL10-6000) / 50L Rotary Evaporator (R-1050) / Diaphragm Vacuum Pump (MP-401)

0.5~2Liter,5Liter,10Liter,20Liter,50Liter Digital Rotary Evaporator

Specifications of explosion-proof 50L Rotary Evaporator:

Model

R-1005EX

R-1010EX

R-1020EX

R-1050EX

Rotary Bottle

5L,diameter of flange opening: Φ50mm

10L,diameter of flange opening:Φ95mm

20L, diameter of flange opening:Φ125mm

50L,diameter of flange opening:Φ125mm

Collecting bottle

10L

20L

Speed-regulation of main machine

Digital display, variable frequency, stepless speed-regulation

Rotary speed of main Machine

10to140r/min,digital display of rotary speed

10to130r/min,digital display of rotary speed

10to110r/min,digital display of rotary speed

Rotaring motor(W)

phase AD induction motor,power:40W

DC motor,power:90W

DC motor, power:180W

DC motor, power:370W

Condensing tube

Vertical type water refrigerating

Standing,main+auxiliary cooling and highly effcient3 circulating coldtrap

Heating boiler

stainless water bath

Temperature control

Digital display, temperature control,0~99℃

Achievable vacuum

399.9Pa (below 3mmHg)

Evaporating capability

Water≥2L/h Alcohol≥6.5L/h

Water≥3.2L/h Alcohol≥6.5L/h

Water≥5L/h Alcohol≥11L/h

Water≥9L/h Alcohol≥19L/h

Elevating function

Manual elevation

Elevating stroke

0~150mm

0~160mm

0~190mm

0~230mm

Rated power supply

220V/50Hz

380V/50Hz

Power of power supply

2.2KW

4.8KW

6.3KW

8.3KW

Dimensions(mm)

765L*400W*1070H

920L*550W*1700H

765L*400W*1070H

1320L*770W*2340H

Explosion-proof tank dimensions(mm)

520L*420W*735H
